WERK
Generous rear and front luggage racks make this an ideal commuter bike for picking up groceries, delivering items, or bringing your things back and forth from the office. Read more ↓
Color Grey
Add-ons our mechanics recommend.
Hand-picked by the eBikes Calgary shop floor and fitted free when you collect.
Built for Calgary roads.
Generous rear and front luggage racks make this an ideal commuter bike for picking up groceries, delivering items, or bringing your things back and forth from the office.
Generous rear and front luggage racks make this an ideal commuter bike for picking up groceries, delivering items, or bringing your things back and forth from the office.
Why this bike
- 150 km
Goes the distance
Calgary-distance range on a single charge. Pathway routes, side streets, and the LRT haul home — all in one tank.
- rack
Hauls the load
Built for cargo. Whether it's the weekly Costco run or a kid-seat commute, the frame and rack do the work.
- 2 yr
In-house warranty
We sell it, we service it. Two-year warranty backed by our own mechanics — walk in, get help.
Specifications.
Full factory spec sheet, grouped for scanning.
Motor & Performance
- Motor
- 500W (Peaks At 750W) Bafang Geared Hub Brushless Motor
- Drive mode
- Drop Out Torque Sensing Pedal Assist with a Throttle
- Torque
- 65Nm of Torque
- Throttle
- Thumb Push Activated Throttle
- Controller
- SURFACE604 Designed 12 MOS 48V 500W 25Ah, Smart Controller
- Top speed
- 20mph (32kmh)*, Comes as Class 2 · (Unlocked) 28mph (45kmh), as Class 3
- Motor harness
- 30Ah, can handle up to 120C current (upgraded)
Battery & Display
- Battery
- Included: 48V 20Ah / 960Wh · Samsung lithium-ion 21700 cells
- Range (rated)
- Upto 90mi (150km) with a 48V20Ah Battery
- Charge time
- 3-4 Hours for a Full Charge from Empty
- Display
- SURFACE604 Color LCD Display with USB Jack · Bigger display: 3.5"
- Battery weight
- 20AH battery 4.65KG/10lbs
Frame & Suspension
- Fork
- SR SUNTOUR XCM 27.5, 80mm with Axle Thru Hub
- Frame notes
- Straight steerer Headtube, Custom Reinforced Battery Mounts, Internal Cable Routing, Post Mount Brakes
- Frame material
- 6061 Aluminum Alloy
- Standover
- Adjustable to the Height of The Rider “One Size Fits All”
- Rider height
- For Riders: M/L 5’7” - 6’6”
- Weight (rated)
- 29.48KG/65 lbs (20AH)
- Max load (rated)
- 300lbs (136kg)
Drivetrain
- Derailleur
- SHIMANO ALIVIO 9-Speed
- Cassette
- SHIMANO 12-34T Cassette
- Shift levers
- SHIMANO ALIVIO 9-Speed
- Crank set
- SAMOX 40T Front Sprocket
- Bottom bracket
- SAMOX Sealed Bottom Bracket
- Pedals
- WELLGO Platform, with Die Casting Body
- Chain
- KMC 9-Speed
Brakes & Wheels
- Brakes
- TEKTRO Auriga Hydraulic Disc Brakes · Post Mount, with Motor Inhibitors
- Rotors
- 180mm Front/Rear x 2.34mm Thick
- Wheels & tires
- 27.5" X 2.6" Custom S604 Panaracer · Tires With Puncture Protection · And Reflective Sidewall
- Rims
- Aluminum Alloy Double Wall Rim, 27.5”x13Gx36H
- Hubs
- Surface604 Aluminum
Lighting & Extras
- Lights
- BÜCHEL "Secu Forte" LED Head Light with 150 lumens and BÜCHEL Rear LED light
- Stem
- SATORI Up2+, Adjustable
- Handlebar
- PROMAX Aluminum, 30mm Rise With 15° Backsweep · 720mm Wide
- Seatpost diameter
- 30.4mm
- Saddle
- Selle Royal Gel Saddle "Essenza Plus" · with elastomer (Relaxed) · suitable for City/Tour use · FLEXITE shell features a unique indented structure, · adding superb flexibility and shock absorption · Adjustable up to 9 degrees.
- Kickstand
- Adjustable Heavy-Duty Aluminum
- Standard features
- Welded Rear Rack, Adjustable Kickstand · Chain Guard, Front Rack Mount, Water Bottle Bosses
- Optional upgrades
- NCX Suspension Seat Post
More specs
- Motor Watts
- 500
- YouTube Review
- zvTvq9apN4A
