SHRED
Balanced and versatile, with a rider friendly layout and upright frame geometry that gives you control and confidence in a huge range of different conditions. Read more ↓
Size S/M
Add-ons our mechanics recommend.
Hand-picked by the eBikes Calgary shop floor and fitted free when you collect.
Built for Calgary roads.
Balanced and versatile, with a rider friendly layout and upright frame geometry that gives you control and confidence in a huge range of different conditions.
Balanced and versatile, with a rider friendly layout and upright frame geometry that gives you control and confidence in a huge range of different conditions.
Why this bike
- 120 km
Goes the distance
Calgary-distance range on a single charge. Pathway routes, side streets, and the LRT haul home — all in one tank.
- rack
Hauls the load
Built for cargo. Whether it's the weekly Costco run or a kid-seat commute, the frame and rack do the work.
- 2 yr
In-house warranty
We sell it, we service it. Two-year warranty backed by our own mechanics — walk in, get help.
Specifications.
Full factory spec sheet, grouped for scanning.
Motor & Performance
- Motor
- eMTB Specific 500W (Peaks At 750W) Bafang Geared Hub Brushless Motor
- Drive mode
- Drop Out Torque Sensing Pedal Assist with a Throttle
- Torque
- 65Nm of Torque
- Throttle
- Thumb Push Activated Throttle
- Controller
- SURFACE604 Designed 12 MOS 48V 500W 25Ah, Smart Controller
- Top speed
- 20mph (32kmh)*, Comes as Class 2 · (Unlocked) 30mph (48kmh), as Class 3
- Motor harness
- 30Ah, can handle up to 120C current
Battery & Display
- Battery
- Included: 48V 20Ah / 960Wh · Samsung lithium-ion 21700 cells
- Range (rated)
- Upto 75mi (120km) with a 48V20Ah Battery
- Charge time
- 3-4 Hours for a Full Charge from Empty
- Display
- SURFACE604 Color LCD Display with USB Jack · Bigger display: 3.5"
- Battery weight
- 20AH battery 4.65KG/10lbs
Frame & Suspension
- Fork
- SR Suntour XCM32 BOOST, 110mm Axle Thru Hub, 130mm travel
- Frame notes
- Tapered Headtube, Custom Reinforced Battery Mounts · Internal Cable Routing, Post Mount Brakes
- Frame material
- 6061 Aluminum Alloy
- Standover
- Small-Medium: 28.5” (724mm) · Medium-Large: 30” (762mm)
- Rider height
- For Riders: S/M 5’2” - 5’7”, M/L 5’8” - 6’6” · Frame Sizes: S/M - 17.5", M/L - 19.5"
- Weight (rated)
- 29.55KG/65lbs (20AH)
- Max load (rated)
- 300lbs (136kg)
Drivetrain
- Derailleur
- SRAM X5 9-Speed 1-Piece Forged CNC with 2 Sealed Bearings
- Cassette
- SRAM 12-34T
- Shift levers
- SRAM X5 Trigger Shift
- Crank set
- SAMOX 38T Front Sprocket, 170mm Crank Arms
- Bottom bracket
- SAMOX Sealed Bottom Bracket
- Pedals
- WELLGO Platform, with Die Casting Body
- Chain
- KMC 9-Speed
Brakes & Wheels
- Brakes
- TEKTRO E500, MTB Specific Hydraulic Disc Brakes · Post Mount, with Motor Inhibitors
- Rotors
- 180mm Front/Rear x 2.34mm Thick
- Wheels & tires
- CST Patrol 27.5" x 2.8"
- Rims
- Aluminum Alloy Double Wall Rim, 27.5″x13Gx36H
- Hubs
- 1-Piece Forged CNC with 2 Sealed Bearings, Cro-Mo Axle and Alloy QR
Lighting & Extras
- Lights
- BÜCHEL "SHINY 120" front headlight with 120 lumens · Pre-Wired To Connect Rear Stop Light
- Stem
- Uno 40 degree Forged
- Headset
- SAMOX Tapered with Sealed Bearings 1 1/8" - 1 1/2"
- Handlebar
- PROMAX Aluminum, 30mm Rise With 9° Backsweep, 720mm Wide
- Seatpost diameter
- 30.4mm
- Saddle
- Selle Royal Gel Saddle "Essenza Plus" · with elastomer (Relaxed) · suitable for City/Tour use · FLEXITE shell features a unique indented structure, · adding superb flexibility and shock absorption · Adjustable up to 9 degrees.
- Kickstand
- Adjustable Heavy-Duty Aluminum
- Standard features
- Adjustable Kickstand, Water Bottle Bosses
- Optional upgrades
- Chain Guide, NCX Suspension · Seat Post, Rear Rack, Rear Led Light, Wren Inverted 110mm 4.82 Lbs Fork
- New for this year
- Bigger wheels, wider tires for smoother ride · New handle bar - more comfortable grip and seating position
More specs
- Motor Watts
- 500
- YouTube Review
- 31dp1KflOLc
